Introduction to the types of led displays, summary of types of led displays

Publisher: Supplier of LED Display Time: 2022-08-09 19:41 Views: 725

When it comes to LED display, I believe everyone is familiar with it. As a display screen, LED display has been all over the streets and alleys, whether it is advertising or notification news, it will be seen. But there are so many LED displays, you must understand which LED display is more suitable for your needs when using it. Next, the editor of LCF will introduce you to the types of LED displays.


Ten categories of LED displays. LED display is a display method by controlling semiconductor light-emitting diodes, which is composed of tens of thousands of semiconductor light-emitting diode pixels evenly arranged. It uses different materials to produce LED pixels of different colors to display text, graphics, images, animations, market quotations, videos, video signals and other information display screens. Currently the most widely used are red, green, yellow, that is, color. The development of blue and pure green LEDs has reached a practical stage.




1.Classification by color base color


(1)Monochrome LED electronic display: single color: red LED electronic display, white LED electronic display, green LED electronic display, yellow LED electronic display, blue LED electronic display, purple LED electronic display ( rose LED electronic display). LED monochrome displays are often used in bus stations, banks, shops, docks, etc.


(2)Dual (primary) color LED electronic display: red and green two primary colors, can display red, green and mixed color yellow. Scope of application: LED dual-color display is mainly used in subways, airports, commercial centers, wedding photo studios, restaurants, etc.


(3)Full-color LED electronic display: red, green, blue three primary colors, 256-level gray-scale full-color display can display more than 16 million colors. LED full-color display can be used in office buildings, high-speed railway stations, commercial advertisements, information release, exhibition centers, etc.


2. according to the installation of indoor and outdoor environment or waterproof classification


(1)Indoor LED electronic display, the main features are low brightness, not waterproof. LED indoor displays are often used in hotel lobbies, supermarkets, KTVs, commercial centers, hospitals, etc.;


(2)Semi-outdoor (sub-outdoor) LED electronic display, the main feature is that it is not waterproof. It is a monochrome LED electronic display that is only used at the door or under the eaves. mention this category;


(3) Outdoor LED electronic display, the main features are high brightness, waterproof, the general waterproof level is IP65 and above. LED outdoor display screens can set off the festive atmosphere, promote corporate product advertisements, transmit information, etc., and are often used in construction, advertising industry, enterprises, parks, etc.


3. Classification by pixel pitch (P or PH) or diameter (Φ)


(1)Single-color LED screen: P10, P8, P7.62 (the old model is called Φ5 according to the diameter), P4.75 (the old model is called Φ3.75 according to the diameter), the old model is called Φ3 according to the diameter (no new models) ;


(2)Conventional indoor full-color LED screen: P7.62, P6, P5, P4, P3, P2.5, P2 (uncommon, unique to a manufacturer: P8, P3.33, etc.);


(3) Small-pitch indoor full-color LED screens: P1.923, P1.875, P1.667, P1.523, P1.4, P1.25, P1.0, P0.87...; One, and is constantly being developed... LED small-pitch screens are often used in airports, schools, transportation, e-sports competitions, central control centers, studios, exhibition halls, conference rooms and other scenes.


(4)Outdoor full color: P20, P16, P12, P13.3, P10, P8, P6, P5, P4, P3 to follow...;


(5)Commonly used on rental screens: P5.68, P4.81, P3.91, P2.97, P2.60...;


(6)Other customization, such as LED spherical screen, subtitle screen, curved screen, streamer screen and other LED special-shaped screens.


4. according to the application industry use environment classification


Advertising screen, door sign screen, information release screen, queuing call screen, service window screen, traffic guidance screen, taxi screen, car screen, stage screen/rental screen, backpack screen, badge screen, workshop signage screen, Environmental monitoring screen, monogram screen, command center monitoring screen, window screen, etc. Among them, the LED rental display can be used in various theme parks, bars, auditoriums, grand theaters, evening parties, building curtain walls, concerts, music festivals and other scenes.


5. Classification by shape


Conventional screen, curved screen, special-shaped screen (such as circular screen, semi-circle screen, parallelogram screen, cylindrical screen and other irregular-shaped screens), creative screen (such as can screen, spherical screen, cube screen, cone screen, tree screen) shape screen, sand table screen, vest screen, backpack screen, dynamic mobile screen, Facebook screen, etc.), grille screen (transparent screen), etc. LED creative display screens can be used in advertising media, stadiums, conference centers, real estate, stages, etc., and LED transparent screens can be used in advertising media, large shopping malls, corporate exhibition halls, exhibitions, etc. .


6. Classification by space


Sky screen, conventional screen, floor tile screen, etc.


7. Classification by Communication Release Method


Conventional screen: stand-alone direct connection, network remote control, U disk.

Wireless screen: GPRS (2G/3G/4G/5G), Bluetooth, WeChat, mobile phone, laptop, tablet.


8. Classification by lamp beads


Plug-in type (old model);


Mounted (new);


Nine, according to the installation method classification


Hanging screen, column screen, hoisting screen, fixed screen, etc. Among them, LED fixed-mounted display screens are often used in TV video programs, VCD or DVD and live broadcasts, advertising and so on.


10. Classification by shape


Generally, it can be divided into circular screen, rectangular screen, curved screen, canned screen, curved screen and so on.


The development prospect of LED display is extremely broad. At present, LED screens are developing in the direction of higher brightness, higher weather resistance, higher luminous density, higher luminous uniformity, reliability, and full color. You will see more types of LED displays appear in the future.
