There is a lot to say about the LED display, now let’s talk about the LED transparent screen secretly. Does the LED transparent screen consume a lot of power? How about the power consumption of the transparent LED display? Today, Liancheng sent the editor to take everyone to take a look.

LED transparent screen has become one of the most eye-catching LED display products in recent years due to its transparent and beautiful characteristics. The 50%-90% transparency greatly reduces the impact on the line of sight and the appearance of the building. Advertisement, when designing the content screen of the advertisement, remove the unnecessary background color and replace it with black, only need to display the expressed content, and the appropriate part does not emit light during playback, which is a transparent effect. This playback method has great Reducing light pollution can also reduce energy consumption, which can save energy by more than 30% compared with ordinary LED displays.

Lianchengfa P7.8-7.8 cabinet:

The power consumption is related to the area of the LED transparent screen, the use time, and the average power consumption, and is affected by two configuration factors: high-brightness and low-brightness. Let's take Lianchengfa led transparent screen (model P7.8-7.8, box size 1000mm*500mm, 1 square) as an example to calculate its power consumption.

1. Low brightness configuration Lianchengfa LED transparent screen P7.8 power consumption and electricity bill details

Lianchengfa low-brightness configuration P7.8LED transparent screen, using positive light-emitting technology, the brightness is about 2500cd/㎡, generally used in purely indoor environments, such as exhibition halls, exhibition halls and other scenes.

The average power consumption is about 240W/㎡, and the power consumption of a 1㎡ screen body is used for 10 hours:

240×10×1 =2400W=2.4KW, which is 2.4 kWh.

Calculated according to the industrial electricity consumption of 0.8 yuan/kWh, the electricity fee of 1.92 yuan is required. Assuming that the total area of the screen is 20㎡, and it plays 25 days a month, the total monthly electricity bill is 1.92×20×25=960 yuan.

2. Highlight configuration Lianchengfa LED transparent screen P7.8 power consumption and electricity bill details

Lianchengfa highlights the configuration of P7.8LED transparent screen, adopts side-emitting technology, and has a brightness of about 5500cd/㎡. It is generally installed indoors and used in scenes such as glass curtain walls of commercial buildings and glass windows of brand chain stores. Because it is for outdoor display, it is therefore Brightness is required.

The average power consumption is about 300W/㎡, and the power consumption of a 1㎡ screen body is used for 10 hours:

300×10×1 =3000W, that is, 3 degrees of electricity.

According to the calculation of 0.8 yuan/kWh of industrial electricity consumption, 2.4 yuan of electricity is required. Assuming that the total area of the screen is 20㎡, and it plays 25 days a month, the total monthly electricity bill is 2.4×20×25=1200 yuan.

The above is the power consumption and cost evaluation method of transparent LED screens compiled by Liancheng Xiaobian for you. I hope it will be helpful to you. At the same time, you are welcome to correct or supplement. Lianchengfa (LCF) is a national-level specialized small giant enterprise, a LED display application and solution provider integrating "hardware + software + content + interaction". The main business covers four major sections: "Smart City", "Cultural Tourism Commercial Performance", "Commercial Display Engineering", and "Content Technology". It has the world's leading automated production equipment, modern post-doctoral research laboratories and comprehensive sales and services. team. Friends who need to buy LED transparent screens and LED displays can also contact us, Lianchengfa led display manufacturer, a big country brand, trustworthy!
