At present, the transparent LED panels produced by many LED display manufacturers are very similar. Even if the appearance is different, the structural principle is the same, such as circuit boards, lamp beads, wires, etc. How to use our fire eye real gold to find a good transparent LED display, the following is the introduction made by the editor.

1. Brightness comparison, place the acrylic board close to the same number of modules and then slowly increase the distance by a small distance to see if the brightness of the lamp beads can meet your own requirements. Of course, it is more direct to put the module directly in the word. The higher the brightness, the higher the requirements for lamp beads, and Chen Ben is also relatively high. The pure indoor environment can use low brightness, but if it is a window LED transparent screen or an LED glass curtain wall screen, then a bright LED transparent screen is required.

2. While watching the brightness, pay attention to whether the light of the lamp bead is uniform. When observing the white light, you must pay attention to whether there is any chromatic aberration (this is very important) - if you cover it with a thin white paper, you may not be able to observe it. , so use a certain thickness of acrylic. The presence or absence of chromatic aberration is the most important part of distinguishing quality, and it is also one of the main reasons for the price difference of LED transparent screens.

3, wire identification. High-quality wire, passed UL certification, these are unreliable through LED transparent screen manufacturers, so the most direct method is to open the outer skin and count the number of wire cores inside! Use 15, 17, 19 cores or even 20, 30 cores The module of the line should be no worse than the module of 14 and 11 cores, and vice versa.

4. Lamp temperature. After lighting for a period of time, touch the LED lamp beads with your hand, the temperature is very high or even hot, and the stability is not as good as the low temperature.

5. The quality of solder joints. The fullness of the solder joints proves that the welding process is good, and the high brightness proves that the solder is used well; the serious ones are virtual soldering, which is prone to poor contact and troublesome follow-up maintenance.

6. LED transparent screen paste light method: At present, there are two production methods for LED transparent screen, one is positive light emission, and the other is side light emission. Although the transmittance of side-emitting light is relatively high, the lamp bead packaging technology needs to be tested by the market, and the light-emitting lamp bead adopts the lamp bead of the traditional LED display screen. After market inspection, the quality is very stable.

7. PCB board thickness. If the positive light-emitting PCB board is thicker, it will affect the transparency of the LED transparent screen.
