Now many LED display manufacturers provide LED display customization services, as long as the customer provides the size area, installation place, environment and so on. But the actual situation in the LED display area is not in accordance with the customer's specific requirements, but a slight gap, why is this?
Originally, the LED display is spliced by a certain number of boxes, and the box is designed according to the number of modules, and the module size is fixed, so the LED display size can only be based on the size of the module and arbitrary design. Display manufacturers generally based on the size of the LED display provided by the customer and the area of the design, can only try to achieve your size, not too far apart.
Here is an example: for example, customers in LCF customized a P10 outdoor full-color display, the initial requirements for the size of 25 meters long, 15 meters wide, a total area of 375 square meters. The P10 outdoor full-color screen module of Lianchengfa has two sizes: 320mm * 320mm and 160mm * 160mm. Here assume the use of 160mm * 160mm module, that is, the length and width are 0.16 meters of the module, then calculate the length and width respectively, the number of boxes needed as follows:
Long need the number of boxes: 25 ÷ 0.16 = 156.25
The number of boxes needed for width: 15÷0.16=93.75pcs
Therefore, LCF gives the customer the size design scheme: 156 modules for length and 94 modules for width, so the actual size of this P10 full-color display is:
Actual length: 156×0.16=24.96 meters
Actual width: 94 × 0.16 = 15.04 meters
Actual area: 24.96 × 15.04 = 375.3984 square meters
It is also worth noting that the current LED box size design is generally about 1 square meter, this is because the LED display box design is too small, it will increase the cost of manufacturers. And too large, it is not convenient to install splicing. Above is the question and answer provided by LCF, more related please pay attention to us.
