How to Calculate the Simple Box Size and Size of P8LED Screen?

Publisher: Supplier of LED Display Time: 2022-08-08 18:08 Views: 680

Simple box size and size calculation of P8LED screen, the display module is installed in front of the outdoor p8 box, and the display driver circuit board is fixed inside the box. The switching power supply is installed on the back cover of the box. An exhaust fan is also installed on the back cover of the box, and the shutters are punched. The box body is sprayed with plastic on the inner and outer surfaces, which has the functions of anti-corrosion, moisture-proof, anti-oxidation, flame retardant, etc., which provides a guarantee for the safety of the display body.



So how to calculate the number of simple cabinets according to the size of the P8LED screen? How big is the P8 full color screen box? In this regard, the editor of Liancheng will share the method with you today.



The P8 LED screen is spliced by a certain number of boxes, and the simple box is composed of a certain number of LED module unit boards, which means that the length/width of the box must be an integer multiple of the length/width of the unit board. , not limited to a multiple.



The model of the P8 full-color LED display has been determined, and the size of the module has been finally determined, which basically determines the size of the box. The size of the P8 full color display module is: 256mm*128mm; then calculate the box size according to the multiple of the module, the size of the P8 LED screen box is: 1024mm*1024mm







In order to facilitate everyone's understanding, here is an example: the customer is customizing the P8LED display, and the required size is 10 meters long, 8 meters wide, and the total area is 80 square meters.



For a simple box with a size of 1024*1024, we can get:



Number of cabinets required for long: 10÷1.024=9.765



The number of boxes required for the width: 8÷1.024=7.8125



The actual size of the P8 full-color screen will be: 10 cabinets in length and 8 cabinets in width.



Actual length of the whole screen: 10×1.024=10.24 meters



The actual width of the whole screen: 8×1.024=8.192 meters



The actual area of the whole screen: 10.24×8.192=83.89 square meters



It is not difficult to conclude from the above that there is a certain error between the actual size of the P8 full-color LED display (10.24 meters long and 8.192 meters wide) and the size required by customers (10 meters long and 8 meters wide), and the results are reliable. It is also worth noting that the size of the outdoor p8 box is not designed according to the number of modules. Generally, the thickness of the simple box of the P8 LED screen is basically between 0.5 square meters and 1.5 square meters, which is too large and is inconvenient to install, transport, and move. If it is too small, it will increase the cost of LED display manufacturers.



Judging from the current market demand, more users have begun to have more requirements on the structure of the full-color LED display waterproof box, and they have begun to develop towards a thin, easy-to-remove box, but from a professional point of view, not all Closed, light and thin will definitely be able to play a waterproof effect, just like your computer case, the box structure only plays the role of dustproof, foreign matter prevention, etc. If a large area of water enters, it will definitely cause internal damage, and the space is too small to prevent Conducive to heat dissipation.
