In today's era of digital display, LED display has become an important tool for information dissemination and visual display. As one of the key indicators to measure the display effect, resolution has a crucial impact on the performance and application of LED display. So, what is the general resolution of the LED display, LCF editorial will analyse in this article for you from a variety of angles.

First, indoor LED display resolution

(A) small pitch LED display

For indoor environments with very high requirements for picture quality, such as high-end conference rooms, command centres, studios, etc., small pitch LED display is widely used. Small pitch usually refers to the pixel pitch in P2.5 and below, such as P1.2, P1.5, P1.8, P2 and other specifications.

Taking P1.2 LED display as an example, the number of pixels per square metre can be as high as 694444. This ultra-high resolution makes the display able to present extremely detailed and realistic image effects, which can meet the needs of complex applications such as ultra-high-definition video playback, precision map display, and large-scale data visualisation. In this case, even if the audience is very close to the display, they can enjoy a grain-free visual experience.

P2 LED display about 250,000 pixels per square metre, in contrast, it is slightly lower than the resolution of P1.2, but still able to provide very high picture quality, and the cost is relatively low, in some of the budget has some limitations but still need high-quality display of the indoor places have been widely used, such as medium-sized conference room of enterprises, showroom and so on.

(B) Conventional indoor LED display screen

In general indoor commercial places, such as shopping malls, hotel lobbies, cinemas, etc., commonly used indoor LED display pixel pitch in P3-P5 or so.

P3 display has about 111111 pixels per square metre, which can clearly display all kinds of advertising and promotional content, event information, film previews and so on. Its resolution can ensure the clarity of images and text, so that viewers can easily access information at a normal viewing distance.

P5 display per square metre of pixels is about 40,000, this display is more advantageous in terms of cost, for some of the requirements of the picture quality is not particularly fine indoor environment, such as small shops, school classrooms, etc., for the display of simple text notices, class schedules, commodity prices, etc. has been enough, and cost-effective.

Second, outdoor LED display resolution

(A) close viewing outdoor LED display screen

In some outdoor close viewing scenes, such as bus stop advertising screen, small information display screen next to the street, etc., the pixel pitch is generally in the P5-P8 or so.

P5 outdoor display is similar to indoor P5 display, with about 40,000 pixels per square metre, which can provide clear content display at a closer viewing distance, such as bus route information at bus stops and advertisements of surrounding businesses.

P8 outdoor display screen has about 15625 pixels per square metre, which ensures a certain degree of clarity at the same time, due to its larger pixel pitch, the cost is relatively low, and it is suitable for use in some scenarios that do not require extremely high display accuracy but need to display information over a large area.

(B) Long-distance viewing of large outdoor LED display screen

For large outdoor advertisement, sports stadium scoreboard, city landmark display screen and other long-distance viewing scenes, the pixel pitch is usually larger, common P10, P16, P20 and so on.

P10 outdoor display has about 10,000 pixels per square metre, this kind of display has high brightness and long viewing distance, it can be clearly seen at a distance of tens of meters or even hundreds of metres, it is suitable to be used for advertisements beside highways, advertisements on the facades of large buildings, etc.

P20 outdoor display about 2500 pixels per square metre, its advantage is that it can be achieved at a relatively low cost of ultra-large area display, despite the relatively low resolution, but in the long-distance viewing, but still be able to effectively convey the content of the advertisement or the score of the event and other important information.

Third, the factors affecting the choice of LED display resolution

(A) viewing distance

Viewing distance is a key factor in determining the resolution of the LED display. If the audience is closer to the display, it needs a higher resolution to ensure the clarity and detail of the image, to avoid the appearance of particles. On the contrary, when the viewing distance is far away, lower resolution display can also meet the visual demand, but also reduce costs.

(B) The complexity of the display content

If you need to display complex images and videos, such as high-definition films and detailed design drawings, then a high-resolution display is essential. And if it is just a simple display of text information or basic graphics, a lower resolution display can do the job.

(C) budget constraints

High-resolution LED display is usually accompanied by higher costs, including hardware procurement, installation, maintenance and other aspects. Therefore, in the case of limited budget, you need to weigh the resolution and cost and choose the most suitable display.

LCF editorial reminds you that the choice of LED display resolution should take into account a variety of factors such as viewing distance, display content and budget. From indoor small pitch high resolution display to outdoor large pitch long distance viewing display, different resolution meets the visual display needs in different scenes, bringing colourful information presentation for our life and business activities.
