Summary of 10 technical indicators of outdoor full-color LED display

Publisher: Supplier of LED Display Time: 2022-08-22 14:21 Views: 374

With the increasing demand for outdoor advertising in the market, the application scale of outdoor full-color LED displays has expanded rapidly. Faced with products with complicated brands on the market, how can industry users buy products that satisfy them? Understanding the parameters of the LED display is the first premise. Next, Liancheng Fa Xiaobian will take you to see the 10 technical indicators of outdoor full-color LED display.

1. Sharpness: Determine the required area of the screen according to the best viewing distance point, and the best distance of "40000 pixels/m2" is 5-50 meters; the most advanced 16-bit data interface is adopted to further improve the clarity of the picture Spend.

2. Brightness: The brightness of the screen is designed to be above 2500cd/m2, which can not only ensure that the indoor full-color LED display has vivid colors and clear images during normal use, but also ensure that the LED display has a high-quality LED display when the lamp attenuates more than 30%. Sufficient brightness and vivid clarity of video images. Refresh rate: Category 5 twisted pair shielded cable is used between the processor and the screen, and a high-performance control IC is configured. The high refresh rate of the screen can be designed at ≧1000HZ to ensure that there is no water ripple and flicker during video playback. All-digital low loss, anti-electromagnetic interference. Power supply and signal transmission method: Because of the importance of full-color LED display, the power supply and signal transmission should be specially treated technically, using high-quality military-grade connector design. Further control failures caused by various pulling forces at the connector.


3. Control method: select the self-designed control system, and conduct 240-hour uninterrupted power-on aging screening, and then select a highly reliable control system. In addition, dual redundant hot backup is adopted in the control mode. Once a problem occurs, another signal line will be connected to it, and it will continue to work normally and connect smoothly.

4. Raw materials: All the raw materials of the LED display screen are made of high-quality brand-name products, and the most important LED lights are high-quality LED lights.

5. Three-level product aging process: firstly, the modules produced by the automated assembly line are energized and aged for 24 hours, and then a single box is energized and aged for 48 hours. Finally, the finished display screen assembled on site is simulated and aged for 72 hours. Shipped to the site for assembly.

6. Product quality control: All products are manufactured in strict accordance with the ISO9001-2000 quality certification system documents. (See the quality certification), will be tested in strict accordance with the waterproof level IP65 to achieve complete waterproof effect. Installation and debugging of LED display: The installation and debugging of LED display shall be carried out strictly according to the design plan, and the installation level shall reach C level or above (the highest level of LED display installation).

7. Leading system software (prepared for re-application on the screen): The operating system adopts Windows XP and supports the latest Windows series products provided by Microsoft. All application software is based on Windows as the operating platform and has a friendly interface. The playback software has rich clock functions, it can display the current date and current time, and the display clock synchronized with the computer's time can be an analog clock or a digital clock. The software adopts advanced thread technology, and can play text, animation, clock, photo, audio, etc. in multiple threads when playing the software.

8. Perfect system function design (prepared for re-application on the screen): This system can meet the requirements of assembly, performance, TV broadcast and advertisement broadcast. The LED display system of this project has multimedia, multi-channel, real-time transmission of high-speed communication data and video interfaces, and can easily introduce various forms of information sources into the computer network system to achieve unified control of various audio and video inputs.

9. The video playback function can display true color dynamic video images, and can broadcast CCTV and satellite TV programs with high fidelity. Various video signal input and output interfaces: composite video, Y/C video (S_Video), YpbPr, VGA (RGBHV), DVI, HDMI, SDI (HDSDI); can play video programs such as video recorders, DVD players (VCD, DVD, LD) with high fidelity; have functions such as superimposing text, animation and static pictures on the video screen; can achieve panoramic views through editing equipment , close-up, slow motion and special effects, and other real-time editing and playback features. Brightness, contrast, saturation, chroma can be adjusted by software, the adjustment range is 256 levels; with image freezing function; with video overlay (VGA+Video), video (Video), VGA three display modes; with horizontal/vertical Position compensation function; with display synchronization function.

10. The computer graphic information playback function can display various computer information, text, graphics, pictures and two- and three-dimensional animations. It has rich playback methods, displays scrolling information, notifications, slogans, etc., and stores a large capacity of data information. The display body can open multiple windows to display the calendar, clock, and insert a single line of flowing text. There are a variety of Chinese fonts and fonts to choose from, and you can also input English, Spanish, French, German, Greek, Japanese, Latin and Russian and many other foreign languages. The broadcasting system has multimedia software, which can flexibly input and broadcast various information. There are more than 20 kinds of broadcasting methods, such as scroll left and right, scroll up and down, push left and right, push up and down, push diagonally, spread, fan, rotate, and zoom. Through the network connection, the network data information is displayed. Equipped with a network interface, it can be connected to the computer and share network resources. It has a standard audio signal output interface to achieve audio and video synchronization.

In addition, the waterproof level of outdoor LED display is a very important technical parameter. It is an important indicator to ensure whether the LED module can work outdoors for a long time. Usually, the waterproof level should reach IP65 in the case of full open air. In order to achieve this waterproof level, every detail from the glue, kit, etc. needs to be done in place, and the quality requirements are very strict.

The above are the 10 major technical indicators of the outdoor full-color LED display screen sorted out by the editor of Liancheng. You are welcome to add or correct them. LCF is a world-leading provider of LED display applications and solutions, as well as a national-level specialized, special, and new little giant enterprise. The main business covers "smart city", "cultural tourism business performance", "commercial display project", "content technology" four major sections, with the world's leading automated production equipment and modern post-doctoral research laboratory and perfect sales and services team. Friends who want to buy LED display can also contact us, LCF LED display manufacturer, a big country brand, trustworthy!
