In the vast map of LED display technology, P10 LED display is like a bright and everlasting star, with unique parameters and size specifications suitable for a variety of scenarios, widely spread in the city streets and alleys, commercial plazas, transport hubs and other outdoor public space, becoming a powerful ‘weapon’ for information dissemination and visual attraction. LCF editor will be in this article in-depth exploration of its parameters and dimensions of the connotation, for everyone to dismantle the door to open the door of a highly efficient outdoor display of precision ‘key’.

First, the core parameters: the definition of the cornerstone of picture quality and performance

1. Pixel Pitch (Pitch): the name of P10, the core from its 10mm pixel pitch, which is one of the most critical parameters of the LED display. It is like a ‘measure’ of image fineness, stipulating the distance between the centres of adjacent pixels and determining the resolution and clarity of the screen. Compared with indoor small pitch (such as P2.5, P1.5) display, P10 pixel spacing is large, close-up particles obvious, but outdoor viewing distance is often more than a few metres or even dozens of metres, this spacing is enough to ensure that the long distance, text sharp, clear image outline, such as high-speed roadside large traffic guidance screen, drivers can easily read the road conditions in the car, warning information, by virtue of the appropriate spacing to match the long view distance scene. Demand.

2. Brightness and contrast: in the outdoor bright light ‘baptism’, P10 display brightness performance is excellent, conventional products up to 5000 - 8000cd / ㎡, some high light models over 10000cd / ㎡, far more than the indoor screen a few hundred to two thousand cd / ㎡ category, to ensure that the picture under the direct sunlight is bright and colourful, the content of the clearly visible under direct sunlight. With high contrast ratio (often more than 3,000:1), rich and vivid colours, white translucent, red hot, blue deep, nightfall picture is not dark, daylight details are not ‘flooded’, from shopping malls to municipal advertisements on the outside wall of the screen, are used to catch the eye of passers-by.

3. Refresh rate and grey level: In order to cope with the smooth playback of dynamic images and the natural demand for colour transition, the refresh rate of P10 display is mostly 1920Hz and above, with a high refresh rate to eliminate flickering and dragging of the screen, so that athletes can run and cars can move smoothly and coherently when broadcasting sports events and presenting dynamic advertisements; the grey level reaches 14-16bit, which means that it has more than 4096-65536 colour levels, so that it can be used for sunset, sunshine, and other events. Gray level of 14 - 16bit, meaning more than 4096 - 65536 colours. Sunset, character skin colour is delicately reproduced, and the realistic texture is shown between light and shadow changes.

Size and specification: flexible customisation, suitable for diversified scenes.

1. Module size and splicing logic: the common specification of P10 display module is 320mm×160mm, and the compact module is like ‘Lego’, which can be flexibly spliced in horizontal and vertical directions according to project requirements. Small convenience store signboards, with a few modules combined into 1 - 2 square metres of simple screen, cost-controlled, easy to install; large outdoor advertising space, hundreds of splicing into dozens of square metres of giant curtain, such as city landmarks side advertising screen, through the scale of the splicing to achieve stunning visual coverage, splicing at the fine craftsmanship, to ensure that the picture is smooth, coherent, no sense of fragmentation.

2. Key points of the whole screen size planning: when designing the whole screen size, consider the physical space of the installation site and the best viewing angle. Plaza centre circular column screen, according to the column perimeter, height to determine the diameter and height size, to ensure that the crowd in all directions comfortable to watch; street wall attached to the screen, the layout of the length and width of the wall, taking into account the pedestrians, vehicles and angle of vision, to avoid obstruction, reflective impact, aspect ratio is often 16:9, 4:3 and other mainstream ratios to match the video material, there are also shaped customization (such as curved to match the curvature of the building) to expand the boundaries of the creative display. The P10 screen is perfectly embedded in the urban fabric.

Third, parameter size synergy: casting outdoor display advantages

P10 display parameters and dimensions closely ‘bite’, and work together. Large size with matching high brightness, refresh rate, to ensure that the grand picture long-distance eye-catching and visual comfort; pixel pitch constraints on the resolution, according to the viewing distance to choose the right size, to prevent too large a screen body, sparse spacing to the near view of the fuzzy or small screen distance under the screen fine but the cost of waste. Like the flight information screen in the airport terminal, the long, large-size P10 screen clearly displays multiple flights with high brightness and excellent refresh rate, adjusting the brightness to the right level with indoor lighting, fine-tuning the parameters according to the scene, and adapting the dimensions according to the space, so that it stands steadily at the ‘forefront’ of outdoor displays. ‘Tide’, with practical, efficient, eye-catching qualities continue to release information dissemination energy, the future with the technology iteration, but also in the precision, energy saving and other dimensions of innovation, expanding the application of the new chapter.

The above is the P10 LED display parameter size that LCF editors have sorted out for you, I hope it is helpful to you, and welcome you to add or correct it.LCF is a set of research and development, intellectual property, sales, operation and service in one of the national speciality and speciality new small giant enterprises, national high-tech enterprises. If you need to buy LED electronic display friends can also directly contact the LED display manufacturer LCF, the big country brand, trustworthy!
